Features

? Fast read access time – 90ns

? Dual voltage range operation

– Unregulated battery power supply range, 2.7V to 3.6V, or

– Standard power supply range, 5V ? 10%

Compatible with JEDEC standard Atmel ? AT27C010

Low-power CMOS operation

– 20μA max standby (less than 1μA, typical) for V CC = 3.6V

– 29mW max active at 5MHz for V CC = 3.6V

JEDEC standard package

– 32-lead PLCC

High-reliability CMOS technology

– 2,000V ESD protection

– 200mA latchup immunity

Rapid programming algorithm – 100μs/byte (typical)

CMOS- and TTL-compatible inputs and outputs

– JEDEC standard for LVTTL and LVBO

Integrated product identification code

Industrial temperature range

Green (Pb/halide-free) packaging option

1Mb (128K x 8)

Unregulated

Battery Voltage,

One-time

Programmable,

Read-only Memory

Atmel AT27BV010

Description

The Atmel AT27BV010 is a high-performance, low-power, low-voltage 1,048,576-bit, one-

time programmable, read-only memory (OTP EPROM) organized as 128K by 8 bits. It

requires only one supply in the range of 2.7V to 3.6V in normal read mode operation, mak-

ing it ideal for fast, portable systems using either regulated or unregulated battery power.

The innovative Atmel design techniques provide fast speeds that rival 5V parts, while keep-

ing the low power consumption of a 3V supply. At V CC = 2.7V, any byte can be accessed in

less than 90ns. With a typical power draw of only 18mW at 5MHz and V CC = 3V, the

AT27BV010 consumes less than one-fifth the power of a standard, 5V EPROM. Standby

mode supply current is typically less than 1μA at 3V. The AT27BV010 simplifies system

design and stretches battery lifetime even further by eliminating the need for power supply

regulation.

The AT27BV010 is available in an industry-standard, JEDEC-approved, one-time

programmable (OTP) PLCC package. All devices feature two-line control (CE, OE) to give

designers the flexibility to prevent bus contention.

The AT27BV010 operating with V CC at 3.0V produces TTL-level outputs that are compatible

with standard TTL logic devices operating at V CC = 5.0V. At V CC = 2.7V, the part is compati-

ble with JEDEC-approved, low-voltage battery operation (LVBO) interface specifications.

The device is also capable of standard, 5V operation, making it ideally suited for dual supply

range systems or card products that are pluggable in both 3V and 5V hosts.

The AT27BV010 has additional features to ensure high quality and efficient production use.

The rapid programming algorithm reduces the time required to program the part and guar-

antees reliable programming. Programming time is typically only 100μs/byte. The

integrated product identification code electronically identifies the device and manufacturer.

0344I–EPROM–4/11
